Tom's
Ham Radio Pix
Before you look at the pictures here is some background
Just some shots of the Shack and a few of me in it.
The computer and VHF side of the Shack. Later I added a Security Camera Monitor and Controler to the right of the computer. Kind of a tight fit but it works !!!
|
Yaesu FTDX 560 - Dentron Super Tuner - MFJ 814 2000 Watt Meter - Heathkit Warrior HA-10 - Astatic D-104 Mike - Antenna is a 390 Foot Long Wire.
 |
Same Shot with the Collins S - Line in the front.
 |
Heathkit "O" Scope - Heathkit DX - 60B Transmitter - Tenma 72-375 Freq Counter - Vanco SWR-2 SWR/Watt Meter - Allied AX 190 Reciever - Heathkit VF 1 VFO - Drake 2-CS External Speaker - Johnson Viking Transmatch - Claricon Dual Crystal Mike.
 |
Another Shot
 |
Notice the Yaesu FT-101B on the left of the Desk instead of the Yaesu FTDX-560.
 |
How do you like the Wallpaper on the computer? She is a Pinup Girl from the 50's.
 |
